ProActive Medical Products
Protekt® STS Compact 500 Sit-to-Stand Patient Lift
Protekt® STS Compact 500 Sit-to-Stand Patient Lift
SKU:34500-COM
Couldn't load pickup availability
The Protekt® STS Compact 500 is an easy-to-use, highly maneuverable sit-to-stand lift engineered for safe patient handling in home and facility environments. With a 500 lb. weight capacity, this electric-powered lift is ideal for individuals who can bear weight but require assistance moving from a seated to standing position. The low 4.9” base height slides effortlessly under most furniture, and the foot pedal-operated base allows smooth wheelchair or toilet access. Featuring a cushioned knee pad, footplate, and standing platform, the STS Compact 500 delivers both comfort and support during transfers.
Built with caregivers in mind, this lift requires minimal physical effort and allows for single-operator use. The actuator includes an emergency quick release for reliable response during power loss. It’s the perfect lift for pressure relief, toileting, dressing, and short-distance transfers.
Medicare code: E0637
Key Features:
500 lb. weight capacity supports wider patient population
Compact frame and 4.9” base height fits under most chairs or furniture
Cushioned knee pad and standing platform for comfort and support
Electric actuator lifts patient from sitting to standing with minimal strain
Foot pedal for hands-free base opening/closing
Emergency quick release actuator for power loss
Modular design for easy part replacement
Smooth-rolling casters for mobility and positioning
| Feature | Protekt® STS Compact 500 (#34500-COM) |
|---|---|
| Weight Capacity | 500 lbs |
| Unit Weight | 111 lbs |
| Base Length | 33.5" |
| Base Closed External Width | 24.9" |
| Mast Height | 40" |
| Front Caster Height | 4.7" |
| Kneepad Height Range | 21", 20", or 19" |
| Kneepad Depth Range | 4" |
| Footplate Width | 13.9" |
| Footplate Length | 14.4" |
| Base Opened Turning Diameter | 45" |
| Base Closed Turning Diameter | 41.9" |
Enhance your lift with these optional accessories:
🔋 Battery – Rechargeable battery pack for uninterrupted power
🔌 Charger with Plug – Standard charger unit
🩲 Charging Cradle (No Plug) – Convenient off-lift charging
🎮 Hand Pendant – Remote lift control
Compatible with:
Protekt® Transformer Lift (Model 33400HE), Protekt® STS Compact 500, Protekt® All-In-One, Protekt® Take-A-Long, Protekt® 500 Stand, Protekt® 600 Stand, Protekt® 500 Lift, Protekt® 600 Lift
Accessories:
| Accessory | SKU |
| Battery | LP-TC12-BPAK |
| Charger (Plug) | LP-TP7C-ADP |
| Charging Cradle (No Plug) | LP-TBC2-CRDL |
| Hand Pendant | LP-TH10-PEN |
Electronics: 2 Years
Frame: 3 Years
Battery: 1 Year
YouTube Video:
Patient Lift Troubleshooting Video
📎 Attachments:
Protekt® STS Compact 500 Individual Product Sheet PDF
